This machine has been exported to many countries like India, Bangladesh, KSA, UAE, Egypt, Morocco, Kenya, South Africa, Vietnam, Indonesia, Malaysia, Chile, Argentina, Brazil, Mexico, Canada, Russia, Ukraine etc.
Moreover, we have the local service India, Vietnam, Indonesia,Russia, Kenya.
Technical Specifications
Model: | PD2016 |
Main Functions | Drilling Hole Steel Plate |
Max. Size of Steel Plate(mm) | 2000x2000x100 |
Max Drilling Dia.*Thickness (mm) | Φ50/Φ80 |
Max. Drilling Stroke(mm) | 180 |
Max.Drilling Speed(rpm) | 600 |
Drilling Spindles(pc): | 1 or 2 Different Dia |
Morse Taper: | Morse 3/Morse 4 |
Auto Clamps Number: | 12 |
Drilling Motor: | 5.5kw |
Quantity of Drilling Holes: | Arbitrariness |
CNC Axis: | 2/3 |
Precision(mm): | +/-0.5 |
Programming Mode: | Input bykeyboard,RS232&USB interface |
Hydraulic System: | Air Self Cooling |
Working Condition: | -10℃-40°CThree Phase 415v 50hz |
Air Force(Mpa): | 1 |
Total Power: | 13.5kw |
Over Dimension: | 3800x2800x2550mm |
Weight: | 6000KGS |
