This machine has been exported to many countries like India, Bangladesh, KSA, UAE, Egypt, Morocco, Kenya, South Africa, Vietnam, Indonesia, Malaysia, Chile, Argentina, Brazil, Mexico, Canada, Russia, Ukraine etc.
Moreover, we have the local service India, Vietnam, Indonesia,Russia, Kenya.
Technical Specifications
Model: | ULF250 |
Main Functions: | Punching Marking Shearing for U/L/Flat Steel |
Size of U Steel(mm) | 100x50x3-250x100x10 |
Size of L Steel(mm) | 50x50x3-150x150x12 |
Size of Flat Steel(mm) | 50x5-250x250x12 |
Top Max Punching Dia.(mm) | Φ26 |
Top Max Punching Oval Dia.(mm) | Φ22x60 |
Top Max. Punching Force(KN): | 1000 |
Top Punchers: | 3/4 |
Marking Force(KN): | 800 |
Dimension of Characters(mm): | 14x10x19mm |
Marking Numbers(pcs) | 12 |
Shearing Force(KN): | 1800 (single blade cutting) |
Max Length of Raw Angle(mm): | 6000/9000/12000 |
Max. Length of Finished Angle Length(mm): | 6000/9000/1200 |
Punches Numbers: | Top 3 Puncher 1 Mark; Left 2 Punchers & Right 2 Punchers Total 8 Die-Stations |
Quantity of Punching Row Per Side: | Arbitrariness |
Groups of Marking Characters: | 1 |
CNC Axis: | 4 |
Shearing Way: | Single Blade Cutting |
Feeding Speed of Angle(m/min): | 80 |
Precision(mm): | +/-0.5 |
Programming Mode: | Input bykeyboard,RS232&USB interface |
Hydraulic System: | Oil |
Working Condition: | -10℃-40°CThree Phase 415v 50hz |
Air Force(Mpa): | 1 |
Total Power: | 42kw |
Over Dimension: | 35000x7500x2350mm |
Weight: | 15000KGS |
This machine has been exported to many countries like India, Bangladesh, KSA, UAE, Egypt, Morocco, Kenya, South Africa, Vietnam, Indonesia, Malaysia, Chile, Argentina, Brazil, Mexico, Canada, Russia, Ukraine etc.
Moreover, we have the local service India, Vietnam, Indonesia,Russia, Kenya.
Technical Specifications
Model: | ULF250 |
Main Functions: | Punching Marking Shearing for U/L/Flat Steel |
Size of U Steel(mm) | 100x50x3-250x100x10 |
Size of L Steel(mm) | 50x50x3-150x150x12 |
Size of Flat Steel(mm) | 50x5-250x250x12 |
Top Max Punching Dia.(mm) | Φ26 |
Top Max Punching Oval Dia.(mm) | Φ22x60 |
Top Max. Punching Force(KN): | 1000 |
Top Punchers: | 3/4 |
Marking Force(KN): | 800 |
Dimension of Characters(mm): | 14x10x19mm |
Marking Numbers(pcs) | 12 |
Shearing Force(KN): | 1800 (single blade cutting) |
Max Length of Raw Angle(mm): | 6000/9000/12000 |
Max. Length of Finished Angle Length(mm): | 6000/9000/1200 |
Punches Numbers: | Top 3 Puncher 1 Mark; Left 2 Punchers & Right 2 Punchers Total 8 Die-Stations |
Quantity of Punching Row Per Side: | Arbitrariness |
Groups of Marking Characters: | 1 |
CNC Axis: | 4 |
Shearing Way: | Single Blade Cutting |
Feeding Speed of Angle(m/min): | 80 |
Precision(mm): | +/-0.5 |
Programming Mode: | Input bykeyboard,RS232&USB interface |
Hydraulic System: | Oil |
Working Condition: | -10℃-40°CThree Phase 415v 50hz |
Air Force(Mpa): | 1 |
Total Power: | 42kw |
Over Dimension: | 35000x7500x2350mm |
Weight: | 15000KGS |
